特点&外观
- intel celeron n2807 cpu
- 2x rj45, 2x usb
- 4x di/o
紧凑型工业级din rail box pc，英特尔®n2807/e3815处理器
- compact-sized industrial grade box pc
- dual-core intel celeron n2807 soc cpu or single-core atom e3815
- esd/surge protection on serial com ports for harsh environments
- wide operating temperature (lec-3030t:-40~70°c)
- fanless design with corrugated aluminum
- support vga display output
- din-rail or wall mounting options
- support 4x di/o
- dual gbe lan ports, 1 x usb 2.0, 1 x usb 3.0 port
- 1 x sata port
产品概述
lec -3030系列是一款紧凑型工业级无风扇盒pc，具有双核intel®celeron®n2807，单核atom e3815(代号baytrail)， ddr3l 1333mhz so-dimm内存高达4gb, 支持din rail/wallmount选项和各种串行com和lan配置，适用于各种工业应用需求。是理想的太阳能光伏监测，风力涡轮机，智能电表，可再生能源或其他现代物联网应用平台。
产品规格
| platform | |
| cpu | intel® celeron n2807 1.58ghz soc cpu or atom e3815 1.46ghz cpu |
| chipset | soc |
| memory technology | ddr3l so-dimm x1 |
| memory capacity | up to 4 gb |
| storage | |
| sata storage | 1 x sata port and hdd kit |
| i/o | |
| ethernet controller | intel i210-it |
| default lan | 2 x rj45 |
| magnetic isolation protection | 1.5kv magnetic isolation protection |
| serial ports | 2 x isolated rs-232/422/485 1 x rs-232 pin header |
| digital i/o | 1 x 2x5 pin terminal block for 4 x di/do |
| usb 2.0 | 1 x type a |
| usb 3.0 | 1 x type a |
| power and mechanical | |
| power input | phoenix contact 2-pin connector with lock, 12 ~ 36 vdc power voltage |
| os and certifications | |
| operating system | microsoft windows 7, windows 7 embedded linux: linux (ubuntu), linux: kernel 2.6 |
| compliance | ce/fcc class a, rohs |
| physical and environmental | |
| storage temperature | -40°c to 85°c |
| operating temperature | -20°c to 55°c |
| operating humidity | 5% to 95% (non-condensing) |
| dimensions (w x h x d) | 52 mm x 130 mm x 127 mm (2.05" x 5.12" x 5.00") |
| weight | 1 kg (2.2 lbs) |
| watchdog | watchdog timer 256 level time interval system reset, software programmable |
订购信息
| lec-3030a | 工业级din轨道无风扇盒pc，英特尔赛扬n2807处理器 |
| lec-3030t | 工业级din轨道无风扇盒pc机，英特尔atom e3815处理器，宽温 |
all product specifications are subject to change without prior notice
