特点&外观
- intel® atom c3000 cpu
- mmwave & sub-6ghz 5g
- rj45/poe , 10gbe sfp
new
配备intel atom®c3000 cpu的5g/wifi6 ready桌面一体机(代号denverton)
- intel® atom c3000 cpu and intel® quickassist technology
- ddr4 1866/2133/2400 mhz, max. 64gb
- 6x gbe rj45 (w/ 2x poe option), 2x 10gbe sfp
- 1x rj45 console, 2x usb 3.0, 1x mini-pcie, 3x m.2
- mpcie expansion slot for edge ai accelerator (intel movidius)
- support for mmwave & sub-6ghz 5g
- support for dual adapters (optional)
产品概述
nca-1516是一款由intel®atom®c3000驱动的桌面网络设备，支持mmwave 5g、sub-6ghz 5g，其wifi6兼容2.4g和5g。硬件性能与英特尔的quickassist技术和英特尔®aes-ni加强。nca-1516配备了充足的网络通信功能和vcpe/ucpe和边缘安全配置。
nca-1516提供了一个mpcie扩展插槽，支持intel movidius myriad x视觉处理单元(vpu)。intel movidius vpu为开发人员创建了一个可靠的硬件平台，用于部署用于智能监控、流量管理、访问控制、零售等领域的健壮的edge aiyb体育app官方下载的解决方案。
产品规格
| platform | |
| form factor | desktop |
| processor options | intel® atom® c3000 |
| cpu socket | 1 x onboard |
| chipset | soc |
| security acceleration | intel® quickassist technology |
| bios | ami spi flash bios |
| system memory | |
| technology | ddr4 1866/2133/2400mhz ecc/non-ecc (by sku) |
| max. capacity | 64gb |
| socket | 2 x 260-pin sodimm |
| networking | |
| ethernet ports | 4 x gbe rj45 intel® i350 2 x gbe rj45 marvell 88e1543 (optional poe support) 2 x sfp soc integrated mac |
| bypass | n/a |
| nic module slot | n/a |
| lom | |
| io interface | n/a |
| opma slot | n/a |
| i/o interface | |
| reset button | 1 |
| led | power/status/storage |
| power button | 1 x atx power switch |
| console | 1 x rj45 |
| usb | 2 x usb 3.0 |
| lcd module | n/a |
| display | n/a |
| power input | 2 x dc jack (optional 2nd dc jack) |
| storage | |
| hdd/ssd support | n/a |
| onboard slots | 1 x onboard emmc 8g (by request) |
| expansion | |
| pcie | n/a |
| mini-pcie | 1 x mini-pcie (pcie/usb2.0) |
| m.2 | 1x m.2 3052/3580 b key (pcie/usb 3.0) 1x m.2 3042 b key (usb 3.0) 1x m.2 2242 b key (sata) |
| sim card slot | 2 x nano sim |
| miscellaneous | |
| watchdog | yes |
| internal rtc with li battery | yes |
| tpm | yes |
| cooling | |
| processor | passive cpu heatsink |
| system | 2 x cooling fans with smart fan or fanless (by request) |
| environmental parameters | |
| temperature | 0~40ºc operating -20~70ºc non-operating |
| humidity (rh) | 5~90% operating 5~95% non-operating |
| system dimensions | |
| (wxdxh) | 231 x 200x 44 mm |
| weight | 1.2 kg |
| package dimensions | |
| (wxdxh) | 358 x 135 x 290 mm |
| weight | 2.75 kg |
| power | |
| type / watts | 60w 5a/12v psu |
| input | ac 100~240v @50~60 hz |
| certification | |
| approvals and compliance | rohs, ce/fcc class b, ul |
订购信息
| nca-1516a | c3958, 2x ddr4 ecc sodimm, 6x gbe rj45 , 2x gbe sfp w/ led, 60w adapter |
| nca-1516b | c3858, 2x ddr4 ecc sodimm, 6x gbe rj45 , 2x gbe sfp w/ led, 60w adapter |
| nca-1516c | c3758, 2x ddr4 ecc sodimm, 6x gbe rj45 , 2x gbe sfp w/ led, 60w adapter |
| nca-1516d | c3558, 2x ddr4 ecc sodimm, 6x gbe rj45 , 2x gbe sfp w/ led, 60w adapter |
all product specifications are subject to change without prior notice
