特点&外观
- 支持intel ivy bridge-ep
- 12个3.5”sas/sata硬盘
- 支持16xrj45 or 8xsfp
- high performance 3u cloud storage appliance with two intel® xeon®
- e5-2600 series processors (sandy/ivy bridge-ep)
概述
fx-3411系列是一款高性能3u机架式的云存储设备，专为数据中心和电信市场设计，支持的sandy/ivy bridge –ep系列cpu，最多可支持12个3.5”sas/sata硬盘以及16个千兆网络接口或8个万兆网络接口。
支持远程管理:通过ipmi卡，可以远程控制和管理网络设备。通过firewall和nats来进行远程配置、系统安装、设备重启和关闭。该卡带有ssl数据加密功能，并附带sdk，客户可以根据自己的需求进行二次开发。
支持cavium nitrox系列安全加速芯片:根据不同的sku选定后，fx-3411可选配cavium nitrox®cn1620安全加速处理器。
可选san卡:支持扩展存储系统。
硬件规格
| form factor | |
| rackmount 3u | |
| platform | |
| processor options | intel® xeon® processor e5-2600 series on lga2011 (sandy bridge-ep or ivy bridge-ep) |
| chipset | intel c604 chipset |
| os support | |
| windows server 2003, 2008, linux kernel 2.6 or above | |
| bios | |
| ami bios 64mb | |
| system memory | |
| technology | quad-channel ddr3 1066/1333/1600 mhz (registered or unbuffered, ecc or non-ecc) |
| max. capacity | 512gb (registered) |
| socket | 16 x 240-pin dimm |
| storage | |
| hdd bays | 12 x 3.5” hdd/ssd kit |
| compact flash | 1 x cf card type ii ast |
| networking | |
| ethernet ports | 1x rj-45 with led for ipmi / management port |
| bypass | depends on nic module bypass specifi-cation |
| controllers | intel ethernet controller, depends on nic module specification |
| nic modules | two |
| management port | one, share with ipmi port |
| i/o interface | |
| reset button | yes |
| console | 1 x rj45 |
| usb | 2 x usb 2.0 |
| opma slot | yes |
| display | vga support via optional ipmi |
| expansion | |
| pcie | 1 x pci-e*8 full height pci-e card in the front 1 x pci-e*8 via riser card with i/o port in the rear |
| pci | n/a |
| cooling | |
| processor | 2 x cpu heatsink with fan duct |
| system | 3 x independent hot-swappable cooling fans with smart fan control |
| environmental parameters | |
| temperature, ambient operating / storage | 0 ~ 40º c / -20~70º c |
| humidity (rh), ambient op-erating and non-operating | 5~95%, non-condensing |
| miscellaneous | |
| lcd module | 128 x 32 text lcm with keypad |
| watchdog | yes |
| internal rtc with li battery | yes |
| physical dimensions | |
| dimensions (wxhxd) | 442 x 132 x 631 mm |
| weight | 35 kg |
| power | |
| type / watts | 800w redundant power supply units |
| input | 90~264v@47~63hz |
| approvals and compliance | |
| ce class a, fcc class a, rohs | |
