特点&外观
- 2x amd epyc 7000 series
- 16x ddr4 512gb max
- 4x or 8x nic module slots
应用交付、网络安全和广域网优化的高性能yb体育app官方下载的解决方案
- amd epyc 7000系列，支持 naples(32c64t)和rome(64c128t)
- 16x 288-pin dimm, max. 512gb ddr4 2666mhz ecc r-dimm
- 2个gbe rj45 intel®i210，最大支持8个网卡模块槽位
- 最大4x个3.5”或2.5”可交换插槽，1个rj45 console
- 2x pcie*8 fhhl或1x pcie*16 fhfl
产品概述
nca-6110是专为网络安全、应用交付和广域网优化而设计的，它支持amd的第二代epyc cpu，代号为rome。这次处理器更新保留了nca-6110的所有其他突出特性。
硬件规格
| platform | |
| form factor | 2u 19” rackmount |
| processor options | amd epyc 7000 series w/ support for naples (up to 32c64t) & rome (up to 64c128t) |
| cpu socket | sp3 |
| chipset | n/a |
| security acceleration | 40gbps encryption 40gbps decryption |
| bios | ami spi flash bios |
| system memory | |
| technology | ddr4 2666mhz ecc reg dimm |
| max. capacity | 512gb |
| socket | 16x 288-pin dimm |
| networking | |
| ethernet ports | 2 x gbe rj45 intel® i210 |
| bypass | n/a |
| nic module slot | 8 or 4 (by sku) |
| lom | |
| io interface | 1 x rj45 |
| opma slot | yes |
| i/o interface | |
| reset button | 1 |
| led | power/status/storage |
| power button | 1 x atx power switch |
| console | 1 x rj45 |
| usb | 2 x usb 3.0 |
| lcd module | n/a |
| display | 1x vga (optional) |
| power input | ac power inlet on psu |
| storage | |
| hdd/ssd support | 4 x 3.5” / 2.5” or 2 x 3.5”/2.5” swappable bays |
| onboard slots | 1 x msata (m.2 by project) |
| expansion | |
| pcie | 2 x pcie*8 fhhl or 1 x pcie*16 fhfl |
| miscellaneous | |
| watchdog | yes |
| internal rtc with li battery | yes |
| tpm | yes (optional) |
| cooling | |
| processor | passive cpu heatsink |
| system | 4 x individual hot-swappable cooling fans |
| environmental parameters | |
| temperature | 0~40ºc operating -20~70ºc non-operating |
| humidity (rh) | 5~90% operating 5~95% non-operating |
| system dimensions | |
| (wxdxh) | 438 x 600 x 88 mm |
| weight | 24 kg |
| package dimensions | |
| (wxdxh) | 825 x 600 x 270 mm |
| weight | 26 kg |
| power | |
| type / watts | 850w 1 1 atx redundant psus |
| input | ac 100v~240v @47~63hz |
| certification | |
| approvals and compliance | rohs, ce/fcc, ul |
订购信息
| nca-6110a |
amd eypc 7000系列，w/支持naples(最多32c64t)和rome(最多64c128t)， 2x gbe rj45, 4x nic模块槽位，1x rj45 console |
| nca-6110b |
amd eypc 7000系列，w/支持naples(最多32c64t)和rome(最多64c128t)， 2x gbe rj45, 8x nic模块槽位，1x rj45 console |
