特点
high performance 3u cloud storage appliance with two intel® xeon®
概述
fx-3411系列是一款高性能3u机架式的云存储设备，专为数据中心和电信市场设计，支持的sandy/ivy bridge –ep系列cpu，最多可支持12个3.5”sas/sata硬盘以及16个千兆网络接口或8个万兆网络接口。
外观
|
form factor |
|
rackmount 3u |
|
platform |
processor options |
intel® xeon® processor e5-2600 series on lga2011 (sandy bridge-ep or ivy bridge-ep) |
|
chipset |
intel c604 chipset |
|
|
os support |
|
windows server 2003, 2008, linux kernel 2.6 or above |
|
bios |
|
ami bios 64mb |
|
system memory |
technology |
quad-channel ddr3 1066/1333/1600 mhz (registered or unbuffered, ecc or non-ecc) |
|
max. capacity |
512gb (registered) |
|
|
socket |
16 x 240-pin dimm |
|
|
storage |
hdd bays |
12 x 3.5” hdd/ssd kit |
|
compact flash |
1 x cf card type ii ast |
|
|
networking |
ethernet ports |
1x rj-45 with led for ipmi / management port |
|
bypass |
depends on nic module bypass specifi- cation |
|
|
controllers |
intel ethernet controller, depends on nic module specification |
|
|
nic modules |
two |
|
|
management port |
one, share with ipmi port |
|
|
i/o interface |
reset button |
yes |
|
console |
1 x rj45 |
|
|
usb |
2 x usb 2.0 |
|
|
opma slot |
yes |
|
|
display |
vga support via optional ipmi |
|
|
expansion |
pcie |
1 x pci-e*8 full height pci-e card in the front 1 x pci-e*8 via riser card with i/o port in the rear |
|
pci |
n/a |
|
|
cooling |
processor |
2 x cpu heatsink with fan duct |
|
system |
3 x independent hot-swappable cooling fans with smart fan control |
|
|
environmental parameters |
temperature, ambient operating / storage |
0 ~ 40º c / -20~70º c |
|
humidity (rh), ambient op- erating and non-operating |
5~95%, non-condensing |
|
|
miscellaneous |
lcd module |
128 x 32 text lcm with keypad |
|
watchdog |
yes |
|
|
internal rtc with li battery |
yes |
|
|
physical dimensions |
dimensions (wxhxd) |
442 x 132 x 631 mm |
|
weight |
35 kg |
|
|
power |
type / watts |
800w redundant power supply units |
|
input |
90~264v@47~63hz |
|
|
approvals and compliance |
|
ce class a, fcc class a, rohs |
